The Quantum Design MPMS 5XL SQUID uses a Superconducting Quantum Interference Device (SQUID) Magnetometer to monitor very small changes in magnetic flux and so discover the magnetic properties of samples. It is extremely sensitive for all kinds of AC and DC magnetic measurements.

The SQUID detects and measures the Magnetic Moment of the sample. From this the magnetization and magnetic susceptibility can be determined.

Applications of the SQUID magnetometer include measurements of small quantities of paramagnetic ions, characterization of all kinds of magnetic materials, and quantitative determination of the number of unpaired electrons in samples. The MPMS-XL provides solutions for a unique class of sensitive magnetic measurements in key areas such as high-temperature superconductivity, biochemistry, and magnetic recording media. .

Data can be collected between H = O to ± 50 kOe and T = 1.7 K to 400 K. The maximum sensitivity of the instrument is in the range of 10-9 emu.

Samples are typically 20 to 40 mg but strongly magnetic materials can be measured with less material.
